Grapple Rake - Severe Duty

The Blue Diamond® Severe Duty Grapple Rake is engineered for the toughest land-clearing, demolition, and material-handling applications. Designed for larger tractors, this rake features replaceable cast teeth, greaseable pivot points, fully enclosed cylinder guards, and heavy-duty American-made cylinders for long-term reliability. Built from American-made steel with massive 3/4" and 1-1/2" thick components, this grapple delivers unmatched durability and performance for professional operators. Its dual, independently operating top clamps and optimal tine spacing make it ideal for moving logs, rocks, brush, scrap, storm debris, and irregular materials.

Product Details

Download Brochure
  • Available in 72", 78", and 84" widths
  • Dual top clamps operate independently for uneven loads
  • Massive 58" grapple opening for oversized materials
  • Heavy-duty 2" × 10" hydraulic cylinders with enclosed covers
  • Constructed from Grade 50 American steel (3/4" & 1-1/2" thick components)
  • Replaceable 23-series pin-on cast teeth
  • Eight (8) heavy-duty tines spaced 9–10" apart
  • Greaseable 1-1/4" pivot pins for long-term reliability
  • Heavy-duty dual 4" square tube mainframe
  • Fits tractors with universal quick-attach mount
  • Recommended for 65+ HP machines
  • Built in the U.S.A.
Part Number Model Weight
Part Number106515 Model72" Grapple Rake, Severe Duty, Dual Clamp Weight1,256 lbs
Part Number106520 Model78" Grapple Rake, Severe Duty, Dual Clamp Weight1,269 lbs
Part Number106525 Model84" Grapple Rake, Severe Duty, Dual Clamp Weight1,350 lbs
