Product Details
Download Brochure- Self-Loading Design – Scoop, carry, and spread material with one attachment.
- 8 or 18 Cu. Ft. Capacities – Match the spreader to your machine and application.
- 30"–30' Spread Range – Adjustable coverage for narrow areas or large surfaces.
- 10–20 GPM Hydraulic Flow – Designed for standard-flow skid steers and CTLs.
- Hydraulic Steel Agitator – Helps maintain consistent material flow and reduce bridging.
- Adjustable Material Gates – Control output for different materials and application rates.
- Hardened Cutting Edge – Built for repeated loading directly from stockpiles.
- Replaceable Bolt-On Paddles – Serviceable wear components help extend attachment life.
- Protective Hopper Grate – Helps keep oversized debris out of the spreading system.
- Universal Skid Steer Mount – Fits most skid steers and compact track loaders.
- Optional Sidewalk Deflector – Provides added control in narrow spreading applications.
| Part Number | Model | Weight |
|---|---|---|
| Part Number101110 | ModelMaterial Spreader, Heavy Duty, 8 cu. ft. | Weight415 lbs |
| Part Number101115 | ModelMaterial Spreader, Heavy Duty, 18 cu. ft. | Weight635 lbs |
| Part Number101155 | ModelSidewalk Deflector Kit For Heavy Duty | Weight27 lbs |
LOAD IT WITH THE SAME ATTACHMENT THAT SPREADS IT
The self-loading design is what sets the Blue Diamond Heavy Duty Material Spreader apart from conventional hopper spreaders. Instead of using another machine or manually loading the hopper, the operator can use the attachment like a bucket to scoop material directly from a stockpile.
Once loaded, transport the material to the application area and engage the hydraulics to begin spreading. The hydraulic-driven steel agitator continually moves material toward the spreading system, helping reduce bridging and maintain a more consistent flow.
Scoop it. Carry it. Spread it. All with one attachment.
CONTROL THE SPREAD
Different applications require different coverage. The Heavy Duty Material Spreader provides a spread pattern ranging from approximately 30 inches to 30 feet, giving operators the flexibility to work across both confined and open areas.
Manually adjustable gates provide a wide range of settings for controlling the amount of material entering the spreader. This makes it easier to adapt output to the material being applied and the coverage required.
For applications that require additional control, an optional Sidewalk Deflector Kit (PN 101155) is available to help limit broadcast into surrounding areas.
ONE SPREADER. MULTIPLE SEASONS.
SNOW & ICE MANAGEMENT
Spread salt and sand across parking lots, roads, driveways, sidewalks, and commercial properties.
TURF & LANDSCAPE
Distribute seed, fertilizer, and lime across lawns, landscaped areas, sports fields, and larger properties.
AGRICULTURE & PROPERTY MAINTENANCE
Use the attachment for compatible granular materials around farms, feedlots, acreage, and other property-maintenance applications.
The multipurpose design helps keep the attachment productive beyond a single season, providing one spreading solution for winter maintenance, turf care, agriculture, and general property maintenance.
BUILT FOR DEMANDING MATERIAL HANDLING
The Heavy Duty Material Spreader is constructed from steel for demanding commercial use. A hardened cutting edge supports repeated self-loading, while the bolted protective grate helps keep unwanted debris out of the spreading mechanism.
Inside the hopper, a hydraulic-driven steel agitator keeps material moving. At the bottom of the system, a reinforced steel spreading disc and replaceable bolt-on paddles distribute material while keeping common wear components serviceable.
Reinforced hydraulic lines, standard couplers, integrated side steps, and a weather-resistant powder-coated finish add practical durability and convenience for everyday operation.
SPECIFICATIONS
| Specification | 8 Cu. Ft. Model | 18 Cu. Ft. Model |
|---|---|---|
| Blue Diamond Part Number | 101110 | 101115 |
| Hopper Capacity | 8 cu. ft. | 18 cu. ft. |
| Hydraulic Flow | 10–20 GPM | 10–20 GPM |
| Recommended Host Machine | 50+ HP | 50+ HP |
| Spread Width | Approx. 30"–30' | Approx. 30"–30' |
| Attachment Weight | 415 lbs. | 635 lbs. |
| Agitator | Hydraulic-driven steel | Hydraulic-driven steel |
| Spreading Disc | Reinforced steel | Reinforced steel |
| Material Control | Adjustable manual gates | Adjustable manual gates |
| Mount | Universal skid steer | Universal skid steer |
Optional Sidewalk Deflector Kit: PN 101155 — 27 lbs.
APPLICATIONS
- Salt spreading
- Sand spreading
- Snow and ice management
- Parking lot maintenance
- Road and driveway maintenance
- Seed spreading
- Fertilizer application
- Lime application
- Lawn and turf care
- Landscaping
- Agricultural applications
- Feedlot and property maintenance
- Compatible bulk granular material spreading
WHY CHOOSE THE BLUE DIAMOND HEAVY DUTY MATERIAL SPREADER?
SELF-LOADING
Scoop directly from the material pile without a second loader or separate loading operation.
YEAR-ROUND VERSATILITY
Spread winter deicing materials as well as seed, fertilizer, lime, and other compatible granular materials.
ADJUSTABLE COVERAGE
Go from narrow spreading applications to coverage up to 30 feet wide.
CONSISTENT MATERIAL FLOW
The hydraulic-driven steel agitator helps reduce material bridging inside the hopper.
BUILT TO BE SERVICEABLE
Replaceable bolt-on paddles and accessible components simplify routine service and wear-part replacement.
BUILT FOR SKID STEERS & CTLs
Universal mounting, 10–20 GPM hydraulic requirements, and a 50+ HP recommendation make machine matching straightforward.
EXPANDED SEO CONTENT
SELF-LOADING SKID STEER SALT, SAND & FERTILIZER SPREADER
The Blue Diamond® Heavy Duty Material Spreader is a self-loading hydraulic skid steer spreader designed to handle salt, sand, seed, fertilizer, lime, and other compatible granular materials. Unlike conventional spreaders that require another machine or manual loading, the hopper features a hardened cutting edge that allows the skid steer operator to scoop material directly from a stockpile.
Available in 8- and 18-cu.-ft. models, the attachment requires 10–20 GPM hydraulic flow and is recommended for skid steers and compact track loaders with 50 HP or more. Its adjustable spreading system provides coverage from approximately 30 inches to 30 feet, allowing one attachment to work across sidewalks and narrow areas as well as driveways, roads, parking lots, lawns, agricultural properties, and large commercial sites.
A hydraulic-driven steel agitator continually moves material inside the hopper to help prevent bridging and maintain consistent flow. Adjustable manual gates control the amount of material delivered to the reinforced steel spreading disc, while replaceable bolt-on paddles provide easy-to-service wear components.
With its combination of self-loading capability, adjustable spreading, rugged steel construction, universal skid steer mounting, and year-round versatility, the Heavy Duty Material Spreader provides an efficient solution for contractors, municipalities, landscapers, property managers, agricultural operations, and snow and ice professionals.
FREQUENTLY ASKED QUESTIONS
What materials can the Blue Diamond Heavy Duty Material Spreader spread?
The attachment is designed for compatible granular materials including salt, sand, seed, fertilizer, and lime, making it suitable for snow and ice management, turf care, landscaping, agriculture, and general property maintenance.
Can the material spreader load itself?
Yes. The attachment features a hardened cutting edge and bucket-style hopper that allows the operator to scoop material directly from a stockpile without leaving the skid steer cab.
What hydraulic flow is required?
The Heavy Duty Material Spreader is designed to operate with 10–20 GPM hydraulic flow.
What size skid steer is recommended?
A skid steer or compact track loader with 50 HP or more is recommended.
How wide can the spreader broadcast material?
Depending on the setup and material, the spreading system provides an adjustable pattern from approximately 30 inches up to 30 feet.
What capacities are available?
Blue Diamond offers an 8-cu.-ft. model (PN 101110) and an 18-cu.-ft. model (PN 101115).
How does the spreader keep material from bridging?
A hydraulic-driven steel agitator rotates inside the hopper to keep material moving toward the spreading system and help maintain consistent feeding.
Can material flow be adjusted?
Yes. Adjustable manual gates allow the operator to regulate material flow for lighter or heavier spreading applications.
Is a sidewalk deflector available?
Yes. The optional Sidewalk Deflector Kit, PN 101155, helps control the spread pattern for narrower applications.
