MINI SKID STEER ATTACHMENTS
MINI-MACHINE MOUNT HYDRAULIC BREAKER
The Blue Diamond® Mini Skid Steer Hydraulic Breaker delivers powerful demolition performance with a rugged mono-block design that eliminates tie rods, requires no nitrogen re-gassing, and features only two internal moving parts for maximum reliability. A polyurethane vibration-dampening shell, energy recovery system, and anti-blank firing protection help maximize productivity while reducing wear on both the breaker and host machine.
Available in four models for carriers from 1,500 to 9,900 pounds, Blue Diamond Hydraulic Breakers are offered with Mini Universal, Bobcat MT, ASV, and Avant mounts to fit a wide range of compact equipment. Backed by a 3-year warranty, they're built for demolition, construction, utility, quarry, and landscaping applications where dependable performance matters.
Product Details
Download Brochure- Available in HB50, HB95, HB165, and HB210 models for carriers from 1,500 to 9,900 lbs
- Solid mono-block housing eliminates tie rods for increased durability and reduced maintenance
- Only two internal moving parts simplify service and improve long-term reliability
- No nitrogen re-gassing required, reducing maintenance and downtime
- Anti-blank firing system protects internal components from dry firing damage
- Energy recovery system maximizes impact energy while reducing hydraulic demand
- Polyurethane vibration-dampening shell minimizes vibration and improves operator comfort
- Two-speed control with variable stroke for optimized breaking performance
- Quiet, self-regulating hydraulic operation
- Body bushings around the piston reduce wear and extend service life
- Available with Mini Universal, Bobcat MT, ASV, and Avant mounts
- Backed by an industry-leading 3-year warranty
| Part Number | Model | Working Pressure | Max Oil Flow | Frequency (BPM) | Tool Diameter | Energy Class | Carrier Weight | Operating Weight | Mount |
|---|---|---|---|---|---|---|---|---|---|
| Part Number335005-25 | ModelHB50 | Working Pressure1,750 | Max Oil Flow7 | Frequency (BPM)1,200 | Tool Diameter1.5 | Energy Class200 | Carrier Weight1,500-2,650 lbs. | Operating Weight132 lbs. | MountMini Universal |
| Part Number335005-26 | ModelHB50 | Working Pressure1,750 | Max Oil Flow7 | Frequency (BPM)1,200 | Tool Diameter1.5 | Energy Class200 | Carrier Weight1,500-2,650 lbs. | Operating Weight132 lbs. | MountBobcat MT |
| Part Number335009-25 | ModelHB95 | Working Pressure1,750 | Max Oil Flow11 | Frequency (BPM)1,200 | Tool Diameter1.8 | Energy Class300 | Carrier Weight2,650-4,000 lbs. | Operating Weight220 lbs. | MountMini Universal |
| Part Number335009-26 | ModelHB95 | Working Pressure1,750 | Max Oil Flow11 | Frequency (BPM)1,200 | Tool Diameter1.8 | Energy Class300 | Carrier Weight2,650-4,000 lbs. | Operating Weight220 lbs. | MountBobcat MT |
| Part Number335009-35 | ModelHB95 | Working Pressure1,750 | Max Oil Flow11 | Frequency (BPM)1,200 | Tool Diameter1.8 | Energy Class300 | Carrier Weight2,650-4,000 lbs. | Operating Weight220 lbs. | MountAvant |
| Part Number335009-36 | ModelHB95 | Working Pressure1,750 | Max Oil Flow11 | Frequency (BPM)1,200 | Tool Diameter1.8 | Energy Class300 | Carrier Weight2,650-4,000 lbs. | Operating Weight220 lbs. | MountASV |
| Part Number335016-25 | ModelHB165 | Working Pressure1,750 | Max Oil Flow13 | Frequency (BPM)1,200 | Tool Diameter2.2 | Energy Class500 | Carrier Weight4,000-6,600 lbs. | Operating Weight370 lbs. | MountMini Universal |
| Part Number335016-26 | ModelHB165 | Working Pressure1,750 | Max Oil Flow13 | Frequency (BPM)1,200 | Tool Diameter2.2 | Energy Class500 | Carrier Weight4,000-6,600 lbs. | Operating Weight370 lbs. | MountBobcat MT |
| Part Number335016-36 | ModelHB165 | Working Pressure1,750 | Max Oil Flow13 | Frequency (BPM)1,200 | Tool Diameter2.2 | Energy Class500 | Carrier Weight4,000-6,600 lbs. | Operating Weight370 lbs. | MountASV |
| Part Number335021-25 | ModelHB210 | Working Pressure1,750 | Max Oil Flow16 | Frequency (BPM)1,100 | Tool Diameter2.5 | Energy Class900 | Carrier Weight6,100-9,900 LBS | Operating Weight463 LBS | MountMini Universal |
