Product Details
Download Brochure- 3,500 lb Attachment Capacity — Handles a variety of landscaping, construction, nursery, and material-handling jobs.
- 51" of Added Reach — Extends the lifting point beyond the top of the skid steer quick attach.
- Heavy Structural Round-Tube Construction — Provides durable support for repeated lifting and positioning.
- 4.5" Main Tube — Creates a strong structural backbone for the boom.
- Chain or Strap Attachment Point — Provides a simple connection for compatible lifting equipment.
- No Auxiliary Hydraulics Required — Simple mechanical design is easy to attach and put to work.
- Versatile Application Range — Useful for trees, pipe, feed totes, landscaping materials, and other stable suspended loads.
- Universal Skid Steer Mount
| Part Number | Model | Weight |
|---|---|---|
| Part Number112005 | ModelTree Boom, 3,500 Lift Cap | Weight169 lbs |
Applications
- Tree planting and setting
- Moving cut trees
- Nursery operations
- Landscaping
- Setting pipe in trenches
- Mechanical contracting
- Scrap-yard material handling
- Lifting feed totes
- Construction material positioning
- Farm and property maintenance
Add Reach for Tree Setting and Landscaping
Tree planting and landscape installation often require more reach than a bucket or pallet fork can provide. The Standard Duty Tree Boom moves the load connection point approximately 51" beyond the top of the quick attach, helping operators position trees and other suspended loads more effectively.
Its 3,500 lb attachment capacity makes it a practical choice for landscapers, nurseries, farms, contractors, and property-maintenance crews that need a simple lifting attachment for everyday work.
Simple, Durable Construction
The Standard Duty Tree Boom keeps the design straightforward. Heavy structural round tubing and a 4.5" main tube provide the structure for lifting work without unnecessary moving components or hydraulic connections.
A dedicated attachment point at the end of the boom accepts a properly rated chain or strap, allowing the operator to configure the attachment for different stable loads.
More Than a Tree-Handling Attachment
Although tree setting is a primary application, the Standard Duty Tree Boom can support many other jobs around the property or jobsite. Blue Diamond identifies applications ranging from pipe placement and mechanical contracting to scrap-yard work and lifting feed totes.
That versatility allows one compact skid steer attachment to support landscaping, construction, agriculture, nursery, and general material-handling operations.
Frequently Asked Questions
What is the capacity of the Standard Duty Tree Boom?
The attachment is rated for 3,500 lbs. Never exceed the rated capacity of the Tree Boom or the host machine.
How much reach does the Standard Duty Tree Boom provide?
The boom extends approximately 51" beyond the top of the quick attach.
What is the Standard Duty Tree Boom used for?
Common applications include setting trees, moving cut trees, nursery work, landscaping, setting pipe in trenches, mechanical contracting, scrap-yard work, and lifting feed totes.
How is a load connected to the Tree Boom?
The end of the boom includes an attachment point designed for use with a properly rated chain or strap.
Does the Tree Boom require hydraulic flow?
No auxiliary hydraulic function is required to operate the Tree Boom itself. Lifting and positioning are performed with the skid steer loader arms.
How much does the Standard Duty Tree Boom weigh?
The published attachment weight is 169 lbs.
