Product Details
Download Brochure- 2,500 lb Lifting Capacity — Provides heavy-duty log-handling capability for tree removal, forestry, and land-clearing operations.
- 63" Maximum Grapple Opening — Accommodates large logs and bulky timber while closing to 4" for secure handling of smaller material.
- Manual or Hydraulic Rotation — Choose the configuration that best matches your machine and material-positioning requirements.
- Aggressive Serrated Grapple Tines — Provide strong gripping traction to help prevent logs from shifting or slipping during handling.
- Reinforced Load Stabilization Brace — Serrated contact surface helps stabilize logs and improve material control during lifting and transport.
- Serrated Boom Design — Provides additional contact and support when stabilizing and positioning timber.
- Heavy-Duty Welded Hydraulic Cylinder — Delivers powerful, dependable clamping force for demanding log-handling applications.
- Protected Hydraulic Hoses — Integrated hose shielding helps protect hydraulic components from branches and job-site debris.
- Rope/Chain Tie-Off Point — Integrated attachment point provides additional utility for appropriate rope or chain applications.
- 8–26 GPM Hydraulic Flow — Compatible with a range of properly equipped skid steers and compact track loaders.
- Greaseable Pivot Points — Accessible lubrication points simplify routine maintenance and support long-term durability.
- Hoses and Couplers Included — High-quality hoses and flat faced couplers are standard.
- Universal Skid Steer mount.
| Part Number | Model | Lift Capacity | Weight |
|---|---|---|---|
| Part Number106815 | ModelLog Grapple, Manual Rotation | Lift Capacity2,500 lbs | Weight500 lbs |
| Part Number306820 | ModelLog Grapple, Hydraulic Rotation and Universal Control Harness | Lift Capacity2,500 lbs | Weight552 lbs |
Heavy-Duty Gripping Power for Professional Tree Work
Take Control of Large Logs and Heavy Timber
Moving heavy logs requires more than lifting capacity. Irregular shapes, uneven weight distribution, and shifting loads demand a specialized attachment designed to maintain a secure grip while providing controlled material movement.
The Blue Diamond Skid Steer Rotating Log Grapple is engineered to handle these challenges. With a 2,500 lb lifting capacity, 63" maximum opening, and powerful hydraulic clamping system, this attachment delivers the strength needed for demanding tree-care and forestry applications.
Aggressive serrated gripping surfaces help hold logs firmly, while the grapple closes to 4" for versatility when handling smaller timber and limbs. The heavy-duty welded hydraulic cylinder provides consistent clamping performance for secure material handling.
Unlike general-purpose root grapples or grapple buckets, the Rotating Log Grapple is specifically designed for gripping, lifting, and positioning individual logs and irregular timber. Its specialized configuration makes it particularly effective for professional tree service crews, log yards, and land-clearing contractors handling large woody material.
Manual or Hydraulic Rotation for Greater Versatility
Position Logs with Greater Precision
Efficient log handling often depends on how accurately operators can position material. Whether loading trailers, sorting timber, or stacking logs, the ability to adjust grapple orientation can reduce unnecessary machine repositioning and improve workflow efficiency.
The Blue Diamond Rotating Log Grapple is available in two configurations to match different operating needs.
Manual Rotation Model
The manual rotation configuration provides a straightforward, durable solution for contractors who need powerful hydraulic gripping capability without an additional hydraulic rotation control system. It is an excellent choice for general log handling, property cleanup, and applications where frequent powered rotation adjustments are not required.
Hydraulic Rotation Model
For operators who regularly handle large or awkwardly positioned logs, the hydraulic rotation model provides additional control over log orientation. The powered rotator allows the operator to adjust grapple positioning using compatible in-cab controls, making it easier to align timber for loading, stacking, and placement.
The hydraulic rotation model includes a universal control harness, with machine-specific electrical compatibility to be confirmed before installation.
Both configurations deliver the same heavy-duty gripping capacity and rugged construction, allowing operators to select the rotation system that best matches their working requirements.
Engineered for Secure Log Stabilization
More Control Over Irregular Loads
Logs are rarely uniform. Uneven weight distribution, irregular shapes, and varying diameters can make timber handling challenging, especially when transporting long or bulky materials.
The Blue Diamond Rotating Log Grapple features an integrated serrated load stabilization brace designed to provide additional support and contact with the material being handled.
Positioned beneath the mounting area, the stabilization brace helps reduce unwanted log movement during lifting and transport. Its serrated edge works with the grapple's aggressive gripping tines to provide additional traction against irregular wood surfaces.
A reinforced serrated boom also provides a contact surface for stabilizing and positioning logs during material-handling operations.
Together, these features help operators maintain better control when moving heavy timber, loading trailers, and organizing material in log yards or land-clearing areas.
For professional tree service and forestry crews, improved load stabilization can make a meaningful difference when handling awkwardly shaped or unevenly balanced logs.
Maximize Your Skid Steer's Timber-Handling Capability
Turn Your Skid Steer into a Versatile Log Handler
Skid steers and compact track loaders are essential machines for contractors working in tree care, land clearing, landscaping, and property maintenance. Adding the Blue Diamond Rotating Log Grapple expands their capabilities with specialized timber-handling performance.
Instead of relying on chains, manual repositioning, or general-purpose buckets to move large logs, operators can use the grapple's hydraulic clamping system to securely grip and position timber with greater control.
The rotating design is particularly useful when working around trees, buildings, equipment, and other obstacles that limit machine positioning. Hydraulic rotation allows operators to adjust log orientation without repeatedly repositioning the host machine.
From moving cut timber during tree removal to organizing logs for processing or loading material for transport, the Rotating Log Grapple helps contractors make more productive use of their existing equipment.
Its heavy-duty construction and versatile gripping range make it a valuable addition for tree service businesses, land-clearing crews, logging operations, and property maintenance professionals.
Built for Durability and Easy Maintenance
Rugged Construction. Dependable Performance.
Tree work and timber handling expose attachments to demanding conditions, including heavy loads, abrasive bark, branches, and irregular materials. The Blue Diamond Rotating Log Grapple is built to withstand these challenges with reinforced steel construction and heavy-duty hydraulic components.
A rugged welded hydraulic cylinder delivers dependable gripping force, while protective hose shielding helps reduce exposure to branches and debris during operation.
Heavy-duty grapple tines, reinforced structural components, and a robust stabilization brace provide the strength needed for repeated lifting, loading, and material-positioning operations.
Accessible grease fittings simplify routine maintenance and help minimize wear on moving components. Five lubrication points allow operators to service the grapple without disassembly, with lubrication recommended every eight hours of operation.
Designed for demanding professional use, the Blue Diamond Rotating Log Grapple combines strength, serviceability, and versatile performance to help keep equipment working productively.
Frequently Asked Questions
What is a skid steer rotating log grapple used for?
A skid steer rotating log grapple is designed to grip, lift, transport, and position logs, timber, and large tree limbs. Common applications include tree removal, land clearing, forestry operations, storm cleanup, log yard work, and timber loading.
How much weight can the Blue Diamond Rotating Log Grapple lift?
The Blue Diamond Skid Steer Rotating Log Grapple has a rated lifting capacity of 2,500 lbs. Actual lifting capability is limited by the host machine's rated operating capacity, attachment weight, load positioning, and working conditions.
What size logs can the Rotating Log Grapple handle?
The grapple opens to 63" and closes to 4", allowing it to handle a wide range of log diameters. Actual material-handling capability depends on log weight, shape, length, gripping position, and the host machine's lifting capacity.
What is the difference between manual and hydraulic rotation?
Both models use hydraulic power to open and close the grapple. The manual rotation model provides a simpler rotation configuration, while the hydraulic rotation model allows operators to control grapple rotation using compatible in-cab controls. Hydraulic rotation is particularly useful for frequent log positioning and loading applications.
Does the hydraulic rotation model require an electrical connection?
Yes. The hydraulic rotation model requires a compatible electrical control harness to operate the rotation function. The current hydraulic rotation model includes a universal control harness. Verify machine-specific control compatibility before ordering.
What hydraulic flow is required for the Rotating Log Grapple?
The recommended hydraulic flow range is 8–26 GPM, with a maximum hydraulic pressure of 3,200 PSI. Check your skid steer or compact track loader's hydraulic specifications before purchasing.
Can the Rotating Log Grapple be used with a compact track loader?
Yes, the attachment can be used with compatible compact track loaders equipped with the appropriate skid steer mounting system, auxiliary hydraulics, and lifting capacity. Hydraulic rotation models also require compatible electrical controls.
How is a rotating log grapple different from a root grapple?
A rotating log grapple is specifically designed to grip and position individual logs and irregular timber. Its rotating configuration, specialized serrated gripping surfaces, and load stabilization brace make it ideal for timber handling. A root grapple is generally designed to collect and move roots, brush, rocks, and mixed debris during land clearing.
How do I maintain the Rotating Log Grapple?
Routine maintenance includes inspecting hydraulic hoses and fittings, checking hardware and grapple components for wear, and lubricating the five grease points every eight hours of operation. Follow the Blue Diamond operator's manual for detailed maintenance and service instructions.
Built to Grip. Engineered to Perform.
From professional tree removal to heavy-duty log yard operations, the Blue Diamond® Skid Steer Rotating Log Grapple delivers powerful gripping performance, precise material control, and rugged construction for demanding timber-handling applications.
