116410

Revision: 000
Ref Item Qty Per Price Stock Qty
Ref: 2 Item:

216705 - BROOM SERIES 2 ANGLE TYPE MOTOR 315cc

 Qty Per: 1 Price:
$1,340.63
Stock:
Brooms
In Stock In Stock

SKU: 216705
Qty:
Ref: 1 Item:

216740 - Pivot Pin 7.5 x 1.25

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 9 Item:

216743 - BROOM SEVERE DUTY SERIES 2 ROTARY HYDRAULIC MANIFOLD BLOCK

 Qty Per: 1 Price:
$537.14
Stock:
Brooms
Low Stock Low Stock

SKU: 216743
Qty:
Ref: 3 Item:

216741 - Bearing

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 10 Item:

216722 - ANGLE BROOM SERIES 2 PIVOT PIN WELDMENT

 Qty Per: 1 Price:
$56.70
Stock:
Brooms
In Stock In Stock

SKU: 216722
Qty:
Ref: 4 Item:

216758 - Bearing Mount Plate​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 19 Item:

216241 - ANGLE BROOM SEVERE DUTY COMPRESSION SPRING ?.312 X 2" OD X 4" LONG

 Qty Per: 1 Price:
$196.61
Stock:
Brooms
Call for Availability 1-888-376-7027

SKU: 216241
Qty:
Ref: 5 Item:

216745 - Mount Weldment​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 22 Item:

216209 - Blue Diamond Wafer 10 x 32 Combo Convoluted

For kit, use 216209-KIT-60

Qty Per: 1 Price:
$29.57
Stock:
Brooms
In Stock In Stock

SKU: 216209
Qty:
Ref: 6 Item:

299493 - Spring Bolt

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 24 Item:

270505 - SKID STEER RIPPER TINE RETAINING PIN W/ CLIP

 Qty Per: 1 Price:
$11.46
Stock:
Miscellaneous Parts
In Stock In Stock

SKU: 270505
Qty:
Ref: 7 Item:

216742​ - Front Hinge Bracket

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 27 Item:

103884 - WIRE HARNESS ATTACHMENT SIDE FOR SWING ARM BRUSH CUTTER AND SEVERE DUTY SERIES 2 ANGLE BROOM

 Qty Per: 1 Price:
$597.79
Stock:
Brooms
Low Stock Low Stock

SKU: 103884
Qty:
Ref: 8 Item:

216747 - Main Frame Pivot Weldment

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 28 Item:

103885 - WIRE HARNESS MACHINE SIDE UNIVERSAL CONTROL FOR SWING ARM BRUSH CUTTER AND SEVERE DUTY SERIES 2 ANGLE BROOM

 Qty Per: 1 Price:
$1,079.00
Stock:
Brooms
In Stock In Stock

SKU: 103885
Qty:
Ref: 11 Item:

216721​ - Main Frame Pivot Pin​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 29 Item:

103887 - WIRE HARNESS MACHINE SIDE 14-PIN FOR SWING ARM BRUSH CUTTER AND SEVERE DUTY SERIES 2 ANGLE BROOM

 Qty Per: 1 Price:
$602.32
Stock:
Brooms
In Stock In Stock

SKU: 103887
Qty:
Ref: 12 Item:

216760 - Spring Bracket​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 30 Item:

103888 - WIRE HARNESS MACHINE SIDE BOBCAT 7-PIN FOR SWING ARM BRUSH CUTTER AND SEVERE DUTY SERIES 2 ANGLE BROOM

 Qty Per: 1 Price:
$1,256.00
Stock:
Brooms
In Stock In Stock

SKU: 103888
Qty:
Ref: 13 Item:

216262-60 - Hood Extension 60"

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 31 Item:

103889 - WIRE HARNESS MACHINE SIDE 8-PIN FOR SWING ARM BRUSH CUTTER AND SEVERE DUTY SERIES 2 ANGLE BROOM

 Qty Per: 1 Price:
$602.32
Stock:
Brooms
Low Stock Low Stock

SKU: 103889
Qty:
Ref: 14 Item:

216744 - Motor Mount Weldment​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 38 Item:

299428 - BOLT GRADE 8 HEX HEAD 3/8"-16 X 1-1/2"

3/8-16 x 1.5" Hex Head​

Qty Per: 1 Price:
$1.41
Stock:
Miscellaneous Parts
In Stock In Stock

SKU: 299428
Qty:
Ref: 15 Item:

216750-60 - Frame Weldment 60"

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 40 Item:

299439 - BOLT GRADE 8 HEX 1/2-13 X 1 3/4" ZINC PLATED

1/2-13 x 1.75" Hex Head​

Qty Per: 1 Price:
$5.51
Stock:
Miscellaneous Parts
In Stock In Stock

SKU: 299439
Qty:
Ref: 16 Item:

216752​ - Support Leg​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 43 Item:

299454 - BOLT GRADE 8 HEX HEAD 3/4"-10 X 2"

3/4-10 x 2" Hex Head​

Qty Per: 1 Price:
$15.39
Stock:
Miscellaneous Parts
In Stock In Stock

SKU: 299454
Qty:
Ref: 17 Item:

216607 - Broom Hub 60"

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 46 Item:

208550 - ROCK BUCKET HD GRAPPLE, 3/8" STOVER LOCK NUT

3/8" Stover​

Qty Per: 1 Price:
$3.26
Stock:
Grapples
In Stock In Stock

SKU: 208550
Qty:
Ref: 18 Item:

216756-60 - Hood 60"

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 47 Item:

299655 - STOVER NUT GRADE 8 1/2-13 (FITS CYLINDER ON SEVERE DUTY HYDRAULIC PALLET FORK)

1/2" Stover​

Qty Per: 1 Price:
$3.26
Stock:
Pallet Forks
In Stock In Stock

SKU: 299655
Qty:
Ref: 20 Item:

216158 - Angle Cylinder - Hydraulic Only​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 48 Item:

299657 - 3/4-10 STOVER NUT GRADE C ZINC PLATED

3/4" Stover​

Qty Per: 1 Price:
$3.26
Stock:
Miscellaneous Parts
In Stock In Stock

SKU: 299657
Qty:
Ref: 21 Item:

216782​ - Bristle Retainer Ring​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 51 Item:

299725 - FLAT WASHER 3/8" GRADE 8

3/8" Washer​

Qty Per: 1 Price:
$1.41
Stock:
Miscellaneous Parts
In Stock In Stock

SKU: 299725
Qty:
Ref: 23 Item:

299659​ - Spring Nut​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 54 Item:

223178 - 1" WASHER FITS SKID SHOE (8 PER BLADE) OR SEVERE DUTY BROOM SPRING (3)

1" Washer (2.5" OD)

Qty Per: 1 Price:
$4.71
Stock:
Miscellaneous Parts
In Stock In Stock

SKU: 223178
Qty:
Ref: 25 Item:

216209-KIT-60 - POLY/STEEL WAFER KIT 60”​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 60 Item:

295010-M12JIC-M12ORB - HYDRAULIC STRAIGHT FITTING MALE #12 JIC X MALE #12 ORING BOSS

 Qty Per: 1 Price:
$11.63
Stock:
Miscellaneous Parts
In Stock In Stock

SKU: 295010-M12JIC-M12ORB
Qty:
Ref: 26 Item:

216746​ - Hose Set

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 70 Item:

224010 - COUPLER, MALE FLAT FACE STYLE, 1/2" Body,1/2" O-RING #8

 Qty Per: 1 Price:
$68.59
Stock:
Brooms
In Stock In Stock

SKU: 224010
Qty:
Ref: 32 Item:

316154 - Water Kit for 60”​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 71 Item:

224009 - COUPLER, FEMALE FLAT FACE STYLE, 1/2" Body 1/2" O-RING #8

 Qty Per: 1 Price:
$99.98
Stock:
Log Splitters
In Stock In Stock

SKU: 224009
Qty:
Ref: 33 Item:

216205-KIT-60 - BROOM WAFER KIT 10 X 32 ALL STEEL FITS 60" MODELS 116408 116410

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 34 Item:

216207-KIT-60 - BROOM WAFER KIT 10 X 32 STANDARD FITS 60" MODELS 116408 116410

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 35 Item:

299317 - 5/16-18 X 1 BOLT HEX HEAD ZINC YELLOW CHROMATE PLATED

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 36 Item:

299318​ - Bearing Shaft Retainer Bolt​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 37 Item:

299315 - Hinge Pivot Pin Bolt​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 39 Item:

299344 - 1/2-13 X 1 1/4 BOLT HEX HEAD GRADE 8 ZINC YELLOW CHROMATE PLATED

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 41 Item:

299433​ - Pivot/Spring Mount to Hinge Weldment Bolt​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 42 Item:

299474​ - 1/2"-13 X 2 1/2" BOLT HEX HEAD GRADE 8 ZINC YELLOW CHROMATE PLATED

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 44 Item:

299493​ - Hinge Spring Bolt​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 45 Item:

299654​ - 5/16-18 STOVER NUT GRADE C ZINC PLATED

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 49 Item:

299659 - Hinge Spring Nut​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 50 Item:

299720 - WASHER ZP 5/16"

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 52 Item:

299830​ - LOCK WASHER 1/2" GRADE 8

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 53 Item:

299732 - WASHER - GRADE 8 - Ø1/2"

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 9 Item:

216743​ - Valve Block​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 55 Item:

216351​ - Solenoid – Small​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 56 Item:

216352​ - Solenoid – Large​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 57 Item:

299321​ - Valve Block Bolt 3/8” X 5” Socket Head Bolt​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 58 Item:

299724 - Valve Block Washer 3/8”​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 59 Item:

208550​ - Valve Block Nut 3/8” Stover​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 61 Item:

216354​ - Manifold Return Port Check Valve Fitting (not required if #21 is present)​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 62 Item:

295020-M12JIC-F12JIC​ - Supply 45 degree fitting at Valve Block​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 63 Item:

295010-M08JIC-M12ORB​ - Motor Supply/Return straight fittings at Valve Block​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 64 Item:

295030-M08JIC-F-8JIC​ - Motor Supply/Return 90 degree fittings at Valve Block​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 65 Item:

216748 - Valve Block Cartridge​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 20 Item:

216158 - Cylinder

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 66 Item:

295030-M06JIC-M08ORB​ - Cylinder Hose 90 degree fittings​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 67 Item:

206052 - Cylinder Base End Straight Restrictor Fitting​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 68 Item:

295020-M08JIC-F08JIC​ - Motor 45 Degree Fittings​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 69 Item:

205010-M08JIC-M10ORB​ - Motor Straight Fittings​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 72 Item:

295010-M12JIC-M08ORB​ - Supply Line Coupler Fitting​

 Qty Per: Price: N/A Stock:
Unavailable
Ref: 73 Item:

216353 - Return Line Check Valve Coupler Fitting (not required if #8 is present)​

 Qty Per: Price: N/A Stock:
Unavailable
