Parts Book

103850

Revision: 000
Ref Item Qty Per Price Stock Qty
Ref: 2 Item:

203402-H - BRUSH CUTTER SEVERE DUTY PISTON MOTOR 150cc WITH HIGH PRESSURE SEAL)

 Qty Per: 1 Price:
$3,226.00
Stock:
In Stock
Qty:
Ref: 1 Item:

203868 - ***not available yet*** BRUSH CUTTER EXCAVATOR SEVERE DUTY CASE DRAIN TO DECK GUSSET HOSE 3/8" X 10" #6 FEMALE 90 DEGREE JIC TO #6 FEMALE 90 DEGREE JIC

 Qty Per: 1 Price: N/A Stock:
Unavailable
Ref: 3 Item:

203810 - BRUSH CUTTER, SEVERE DUTY, MINI EXCAVATOR, 80CC MOTOR MOUNT FLANGE

 Qty Per: 1 Price:
$395.38
Stock:
In Stock
Qty:
Ref: 12 Item:

203889 - BRUSH CUTTER EXCAVATOR SEVERE DUTY SIDE ACCESS COVER SET

 Qty Per: 2 Price: N/A Stock:
Unavailable
Ref: 4 Item:

203109 - BRUSH CUTTER, DIRECT DRIVE BELLOW ASSEMBLY (SMALL STRAIGHT THREAD FOR GREASE OUTLET)

 Qty Per: 1 Price:
$61.09
Stock:
In Stock
Qty:
Ref: 13 Item:

203885 - BRUSH CUTTER SEVERE DUTY EXCAVATOR DISCHARGE DEFLECTOR WITH HARDWARE (REQ'S 2)

 Qty Per: 2 Price: N/A Stock:
Unavailable
Ref: 5 Item:

203076 - BRUSH CUTTER DIRECT DRIVE HOUSING ONLY, WIDE TOP C-FLANGE

 Qty Per: 1 Price:
$1,417.00
Stock:
In Stock
Qty:
Ref: 6 Item:

203424 - BRUSH CUTTER, HIGH FLOW & SEVERE DUTY, LARGE VALVE CARTRIDGE

 Qty Per: 2 Price:
$263.23
Stock:
In Stock
Qty:
Ref: 7 Item:

203451 - BRUSH CUTTER SEVERE DUTY MOTOR FLANGE RING OIL SEAL HC05 150 200 250CC

 Qty Per: 1 Price:
$48.90
Stock:
In Stock
Qty:
Ref: 8 Item:

203453 - BRUSH CUTTER SEVERE DUTY MOTOR SAE C-FLANGE O-RING HC05 150 200 250CC

 Qty Per: 1 Price:
$7.69
Stock:
Low Stock
Qty:
Ref: 9 Item:

203424-L - BRUSH CUTTER HIGH FLOW VALVE CARTRIDGE O-RING - LARGE (MIDDLE)

 Qty Per: 2 Price:
$1.41
Stock:
In Stock
Qty:
Ref: 10 Item:

203424-S - BRUSH CUTTER HIGH FLOW VALVE CARTRIDGE O-RING - SMALL (END)

 Qty Per: 2 Price:
$1.41
Stock:
In Stock
Qty:
Ref: 11 Item:

203424-T - BRUSH CUTTER HIGH FLOW VALVE CARTRIDGE SPLIT RING

 Qty Per: 2 Price:
$2.13
Stock:
In Stock
Qty:
Ref: 15 Item:

203008 - BRUSH CUTTER INSPECTION COVER

 Qty Per: 1 Price:
$40.05
Stock:
In Stock
Qty:
Ref: 14 Item:

216402 - STORAGE TUBE FOR MANUAL

 Qty Per: 1 Price:
$24.53
Stock:
In Stock
Qty:
Ref: 16 Item:

203066 - BRUSH CUTTER DIRECT DRIVE SPINDLE ONLY 1/2" blade carrier bolts (TAPERED STYLE) get S/N

 Qty Per: 1 Price:
$1,421.00
Stock:
Low Stock
Qty:
Ref: 17 Item:

203043 - BRUSH CUTTER BLADE CARRIER 60" HD/EXTREME 3/4 BOLT HOLES (3 BLADE)

 Qty Per: 1 Price:
$1,097.00
Stock:
Low Stock
Qty:
Ref: 18 Item:

203028 - BRUSH CUTTER BLADE, HD Series 2 (13 1/8" LONG FROM THE CENTER OF THE BOLT HOLE) (60" only)

For Kit, use 203028-KIT

Qty Per: 3 Price:
$117.70
Stock:
In Stock
Qty:
Ref: 19 Item:

203035 - BRUSH CUTTER BLADE BOLT FITS ALL SKID STEER MINI SKID MINI EX MODELS

 Qty Per: 3 Price:
$46.32
Stock:
In Stock
Qty:
Ref: 20 Item:

203030 - BRUSH CUTTER BLADE NUT FITS ALL SKID STEER MINI SKID MINI EX MODELS

 Qty Per: 3 Price:
$20.81
Stock:
In Stock
Qty:
Ref: 21 Item:

203417 - BRUSH CUTTER, SEVERE DUTY, VALVE BLOCK FOR PISTON MOTORS 150CC, 200CC, 250CC

 Qty Per: 1 Price:
$884.03
Stock:
In Stock
Qty:
Ref: 22 Item:

203028-KIT - 60" CUTTER BLADE KIT - ALL CURRENT MODELS (3 W/ HARDWARE - CHECK BLADE LENGTH 13") 3203028

 Qty Per: 1 Price:
$363.19
Stock:
In Stock
Qty:
Ref: 23 Item:

203914 - BRUSH CUTTER WIRE PROTECTION, LOWER BUSHING & BOLT-REQUIRES 5

 Qty Per: 5 Price:
$30.09
Stock:
In Stock
Qty:
Ref: 24 Item:

203134 - BRUSH CUTTER UPPER SEAL GUARD RING (ring style) 3/4" holes

 Qty Per: 1 Price:
$302.14
Stock:
In Stock
Qty:
Ref: 25 Item:

203056 - BRUSH CUTTER HOUSING BOLT & NUT 3/4" (short for ring style wire protection)

 Qty Per: 6 Price:
$12.15
Stock:
In Stock
Qty:
Ref: 26 Item:

203086 - BRUSH CUTTER DIRECT DRIVE MAIN SEAL, LARGE BEARING STYLE (GET S/N) for 3" spindle

 Qty Per: 1 Price:
$123.85
Stock:
In Stock
Qty:
Ref: 27 Item:

203074 - BRUSH CUTTER DIRECT DRIVE LOWER BEARING & RACE (5" DIAMETER) get S/N for 3" spindle

 Qty Per: 1 Price:
$222.73
Stock:
In Stock
Qty:
Ref: 28 Item:

203072 - GREASE ZERK FOR BRUSH CUTTER DIRECT DRIVE HOUSING, PICKUP BROOM

 Qty Per: 1 Price:
$5.33
Stock:
In Stock
Qty:
Ref: 29 Item:

203075 - BRUSH CUTTER DIRECT DRIVE BEARING AND RACE (4.5" DIAMETER) 2 5/8" spindle requires 2, 3" spindle requires 1x + 1x 203074

 Qty Per: 1 Price:
$158.72
Stock:
In Stock
Qty:
Ref: 30 Item:

203105 - BRUSH CUTTER DIRECT DRIVE SPINDLE NUT LOWER

 Qty Per: 1 Price:
$41.79
Stock:
In Stock
Qty:
Ref: 31 Item:

203095 - BRUSH CUTTER DIRECT DRIVE LOCK RING

 Qty Per: 1 Price:
$96.68
Stock:
In Stock
Qty:
Ref: 32 Item:

203100 - BRUSH CUTTER STAR LOCK WASHER

 Qty Per: 1 Price:
$38.77
Stock:
In Stock
Qty:
Ref: 33 Item:

203090 - BRUSH CUTTER DIRECT DRIVE SPINDLE NUT UPPER

 Qty Per: 1 Price:
$32.68
Stock:
In Stock
Qty:
Ref: 34 Item:

203087 - BRUSH CUTTER DIRECT DRIVE, RETENTION RING (FITS LARGE BEARING STYLE SEAL UNITS)

 Qty Per: 1 Price:
$38.12
Stock:
In Stock
Qty:
Ref: 35 Item:

203073 - BRUSH CUTTER, DIRECT DRIVE ASSEMBLY, TAPERED SPINDLE, WIDE TOP HIGH FLOW OR SEVERE DUTY, FITS 3/4" blade carrier bolts

 Qty Per: 1 Price:
$3,051.00
Stock:
In Stock
Qty:
